Voltage: 12.8V
Capacity: 20Ah
Energy: 256Wh
Size：181*77*168mm
|
Items |
Parameter |
Note |
|||||
|
Normal Voltage |
12.8V |
25℃±3℃ |
|||||
|
Material of Battery |
LiFePO4 |
|
|||||
|
Charge limit voltage |
14.6V |
|
|||||
|
Discharge limit voltage |
10V |
|
|||||
|
Charge current |
0.2C |
|
|||||
|
Max. charge current |
0.5C |
|
|||||
|
Discharge Current |
0.5C |
|
|||||
|
Max. discharge current |
1C |
|
|||||
|
Peak discharge current |
2C，10S |
|
|||||
|
Material of casing |
Plastic casing |
|
|||||
|
Charge Temperature |
0~50℃ |
|
|||||
|
Discharge Temperature |
-20~60℃ |
|
|||||
|
Storage Temperature |
0-45℃ |
|
|||||
|
Cycle time |
4000 cycles, 0.2C/0.2C |
the capacity retention rate ≥80% |
|||||
|
Number of series |
≤4pcs |
|
|||||
|
Number of parallel |
≤4pcs |
|
|||||
|
Voltage |
Capacity |
Energy |
Terminal |
Size |
Weight |
||
|
12.8V LiFePO4 Battery Pack |
7Ah |
89.6Wh |
T2 |
151*65*95mm |
About 0.8kg |
||
|
12Ah |
153.6Wh |
T2 |
151*99*95mm |
About 1.4kg |
|||
|
20Ah |
256Wh |
M5 |
181*77*168mm |
About 2.5kg |
|||
|
50Ah |
640Wh |
M8 |
198*166*170mm |
About 6kg |
|||
|
75Ah |
960Wh |
M8 |
260*168*211mm |
About 7.5kg |
|||
|
100Ah |
1280Wh |
M8 |
328*172*215mm |
About 11kg |
|||
|
200Ah |
2560Wh |
M8 |
522*240*218mm |
About 21kg |
|||
|
300Ah |
3840Wh |
M8 |
520*268*220mm |
About 30kg |
|||
